The Aimpoint® Duty RDS is a compact, high-grade reflex optic that was designed to meet the demanding needs of the modern law enforcement officer.
The Duty RDS™ (Red Dot Sight) offers a bright, crisp 2 MOA dot that’s ideal for short to medium range target engagements. All new windage and elevation adjustments are flush mounted and waterproof, eliminating the need for protective caps. The turrets provide audible “clicks” when zeroing the optic. The dot brightness intensity switch is a digital keypad with intuitive push buttons that can easily be manipulated while wearing gloves. The pressure forged aluminum alloy housing provides durability against extreme abuse and drastic temperature changes. The Duty RDS comes with a one-piece torsion nut mount that attaches to MIL-STD-1913 picatinny rails. The sight is fully compatible with all generations of night vision devices.
The Duty RDS withstands extremely tough handling and offers Aimpoint quality at a more accessible price point.

Key features:

– 2 MOA dot size
– 30,000 hours (over 3 years) of constant operation on setting 7
– 4 night vision compatible settings, and 6 daylight settings
– Weight 108 g (3.8 oz) sight only
– Submersible to 25 meters (80 feet)
– Advanced optical lenses for enhanced light transmission and ultimate dot clarity
– Height of Optical Axis 39 mm (1.5 in) measured from top surface of mounting platform
– One-piece Torsion Nut Mount – Integral Picatinny-style base allows easy attachment to any picatinny rail
– Flip-up lens covers – front is solid, and rear is transparent – allowing the user to shoot with both eyes open and lens caps closed in an emergency situation
– Advanced optical lenses for enhanced light transmission and ultimate dot clarity
– Windage and elevation adjustments are flush mounted and waterproof – eliminating the need for protective caps
– Hard anodized non-reflective surface
– A compact, high-grade red dot reflex optic designed for the modern law enforcement officer

INCLUDES: One-piece Torsion Nut Mount, Flip-Up lens covers, CR2032 battery, Allen T10 wrench


Dot size2MOA
Night Vision Device (NVD) compatibleYes
TransmissionAverage >85% in the range 420-620nm
DiodeLED totally eye safe
Dot colorRed
Light source wavelength650nm red light
Optical coatingAnti-reflex coating all surfaces and multilayer coating objective lens
Optical signatureNo optical signature is visible at 10 meter distance, front side, on appropriate settings with NVD
Clear aperture18mm / 0.7in
ParallaxAbsence of parallax – No centering required
Battery life30,000h at daylight setting 7 (15,000 Lux, room temperature)
Battery typeCR2032 3V Lithium
Power switchPush buttons
Night Vision Device (NVD) settings4
Daylight (DL) settings6
Start setting position7
Size80 x 38 x 67 mm / 3.1 x 1.5 x 2.6 in
Weight161g / 5.7oz
Size (Sight only)68 x 37 x 43 mm / 2.7 x 1.5 x 1.7 in
Weight (Sight only)108g / 3.8oz
Material housing and tubeHigh strength aluminum
Surface finish housingAnodized, Semi-Matte
Color housingBlack
Lens coversFlip-Up lens covers, Front solid and rear transparent
Material lens coversThermoplastic elastomer (TPE)
Material mounting solutionAluminum
Adjustment1 click 15mm at 100m / ≈ 0.5in at 100yds
